沼氣進入沼氣發電機組之前需要預處理，由于糞便產生的沼氣除含有大量的甲烷和二氧化碳外，還含有其他如硫化氫、雜質、水分、氮氧化合物、硅氧烷等組分。糞便厭氧發酵產生的沼氣中硫化氫含量大，會對后端的設備產生腐蝕作用，因此進行了沼氣脫硫的處理。
Biogas needs to be pretreated before entering the biogas generator unit. In addition to a large amount of methane and carbon dioxide, the biogas produced by feces also contains other components such as hydrogen sulfide, impurities, water, nitrogen oxides and siloxanes. The biogas produced by fecal anaerobic fermentation has a large content of hydrogen sulfide, which will corrode the equipment at the back end. Therefore, the biogas desulfurization treatment was carried out.
未經處理的沼氣不符合發動機氣體品質的要求。沼氣直接進入發動機，可能會引起功率波動、機組敲缸、停機甚至爆炸。若氣體只是做了簡單的處理，水分、含塵量、壓力、溫度等均不符合機組要求。由于積水導致了凝結水在管道的大量聚集，機組的可用率和發電功率大幅度下降；含塵量過高導致壓力損耗過大，且機組內部缸體損耗嚴重；壓力、溫度等不符合機組要求，機組頻繁跳機，可用率大幅下降且增加了維護檢修成本。而經過改造后的氣體預處理，機組的發電量可以增加70%。所以，氣體品質處理的效果如何，直接影響到終的機組工作效率，從而影響收益。所以選用好的預處理設備進行氣體的除濕、除雜、穩壓、恒溫等等工作是保證效益的前提。
Untreated biogas does not meet the requirements of engine gas quality. Biogas directly enters the engine, which may cause power fluctuation, unit cylinder knocking, shutdown or even explosion. If the gas is simply treated, the moisture, dust content, pressure and temperature do not meet the requirements of the unit. Due to water accumulation, a large amount of condensed water is accumulated in the pipeline, and the availability and power generation of the unit are greatly reduced; Excessive dust content leads to excessive pressure loss and serious loss of cylinder block inside the unit; The pressure, temperature, etc. do not meet the requirements of the unit, the unit frequently trips, the availability rate drops significantly, and the maintenance cost is increased. After the gas pretreatment, the power generation of the unit can be increased by 70%. Therefore, the effect of gas quality treatment will directly affect the working efficiency of the final unit and thus affect the income. Therefore, selecting good pretreatment equipment for gas dehumidification, impurity removal, pressure stabilization, constant temperature and other work is the premise to ensure efficiency.
沼氣發電機組對使用環境及沼氣的基本要求：
The basic requirements of biogas generator set for use environment and biogas:
1.燃?xì)膺M(jìn)氣壓力為2-10kpa,發電機組的氣體壓力過高或過低則需加調壓閥或增壓設備；
1. The gas inlet pressure is 2-10kpa. If the gas pressure of the generator set is too high or too low, the pressure regulating valve or booster device shall be added;
2.燃?xì)庵胁缓坞x水和大于5μm的游離物質，燃?xì)庵辛蚧瘹浜啃璧陀?0ppm；
2. The fuel gas does not contain free water and more than 5 μ M U.M, and the hydrogen sulfide content in the gas shall be less than 10ppm;
3.機組一般使用環境：溫度5℃~35℃，海拔高度≤500m；
3. General operating environment of the unit: temperature 5 ℃ ~ 35 ℃, altitude ≤ 500m;
備注：燃?xì)庵辛蚧瘹浜窟^高時，對燃?xì)鈾C組零部件會造成一定的腐蝕，影響機組正常使用及機組使用壽命。。
Note: when the hydrogen sulfide content in the gas is too high, it will cause certain corrosion to the parts of the gas unit, affecting the normal use of the unit and the service life of the unit..
The above is the detailed introduction of biogas desulfurization for you. I hope it will help you. If you have any questions, please contact us. We will provide services for you with a professional attitude http://www.cdbsj.com
